STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS6000 Searies



Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS605 5 14 5 6 2.381 0.3 0.0045
SS606 6 17 6 8 2.381 0.3 0.006
SS607 7 19 6 6 3.969 0.3 0.007
SS608 8 22 7 7 3.969 0.3 0.015
SS609 9 24 7 7 3.969 0.3 0.016
SS6000 10 26 8 7 4.763 0.3 0.019
SS6001 12 28 8 8 4.763 0.3 0.022
SS6002 15 32 9 9 4.763 0.3 0.031
SS6003 17 35 10 10 4.763 0.3 0.04
SS6004 20 42 12 9 6.35 0.6 0.068
SS6005 25 47 12 10 6.35 0.6 0.078
SS6006 30 55 13 11 6.747 1 0.11
SS6007 35 62 14 11 7.938 1 0.148
SS6008 40 68 15 12 7.938 1 0.185
SS6009 45 75 16 12 9 1 0.23
SS6010 50 80 16 13 9 1 0.258
SS6011 55 90 18 11 11.1125 1 0.362
SS6012 60 95 18 13 11.1125 1 0.385
SS6013 65 100 18 13 11.1125 1 0.41
SS6014 70 110 20 13 12 1 0.575
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS6200 Searies
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS625 5 16 5 8 2.381 0.3 0.005
SS626 6 19 6 6 3.969 0.3 0.008
SS627 7 22 7 7 3.969 0.3 0.014
SS628 8 24 8 7 3.969 0.3 0.016
SS629 9 26 8 7 4.763 0.3 0.019
SS6200 10 30 9 8 4.763 0.6 0.032
SS6201 12 32 10 7 5.953 0.6 0.035
SS6202 15 35 11 8 5.953 0.6 0.045
SS6203 17 40 12 8 6.747 0.6 0.064
SS6204 20 47 14 8 7.938 1 0.103
SS6205 25 52 15 9 7.938 1 0.127
SS6206 30 62 16 9 9.525 1 0.2
SS6207 35 72 17 9 11.11 1 0.288
SS6208 40 80 18 9 12 1 0.368
SS6209 45 85 19 10 12 1 0.416
SS6210 50 90 20 10 12.7 1 0.463
SS6211 55 100 21 10 14.288 1.5 0.602
SS6212 60 110 22 10 15.08 1.5 0.789
SS6213 65 120 23 10 16.668 1.5 0.99
SS6214 70 130 24 11 16.668 1.5 1.084
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS6300 searies
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS6300 10 35 11 7 6.35 0.6 0.053
SS6301 12 37 12 6 7.938 1 0.061
SS6302 15 42 13 7 7.938 1 0.08
SS6303 17 47 14 7 7.938 1 0.109
SS6304 20 52 15 7 9.525 1 0.142
SS6305 25 62 17 7 11.11 1 0.219
SS6306 30 72 19 8 12 1 0.349
SS6307 35 80 21 7 14.288 1.5 0.455
SS6308 40 90 23 8 15.08 1.5 0.639
SS6309 45 100 25 8 17.462 1.5 0.873
SS6310 50 110 27 8 19.05 2 1.082
SS6311 55 120 29 8 20.63 2 1.368
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS6700,SS6800,SS6900 Searies
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS6700 10 15 3 0.2
SS6701 12 18 4 0.2
SS6702 15 21 4 0.2
SS6703 17 23 4 0.2
SS6704 20 27 4 0.2
SS6705 25 32 4 0.2
SS6706 30 37 4 0.2
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS6800 10 19 5 9 2.381 0.3 0.005
SS6801 12 21 5 12 2.381 0.3 0.006
SS6802 15 24 5 14 2.381 0.3 0.007
SS6803 17 26 5 15 2.381 0.3 0.008
SS6804 20 32 7 14 3.175 0.3 0.019
SS6805 25 37 7 16 3.175 0.3 0.022
SS6806 30 42 7 19 3.175 0.3 0.026
SS6807 35 47 7 22 3.175 0.3 0.029
SS6808 40 52 7 24 3.175 0.3 0.035
SS6809 45 58 7 0.3 0.04
SS6810 50 65 7 0.3 0.052
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS6900 10 22 6 9 3.175 0.3 0.009
SS6901 12 24 6 10 3.175 0.3 0.011
SS6902 15 28 7 10 3.969 0.3 0.016
SS6903 17 30 7 11 3.969 0.3 0.018
SS6904 20 37 9 11 4.763 0.3 0.036
SS6905 25 42 9 12 4.763 0.3 0.042
SS6906 30 47 9 14 4.763 0.3 0.048
SS6907 35 55 10 13 5.953 0.6 0.074
SS6908 40 62 12 13 6.747 0.6 0.112
SS6909 45 68 12 0.6 0.13
SS6910 50 72 12 0.6 0.133
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS "R" Searies
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SSR6 OPEN 9.525 22.225 5.558 7 3.969 0.3 0.014
ZZ 7.142
SSR8 OPEN 12.7 28.575 6.35 8 4.763 0.3 0.015
ZZ 7.9375
SSR10 OPEN 15.875 34.925 7.142 10 4.763 0.6 0.028
ZZ 8.732
SSR12 OPEN 19.05 41.275 7.9375 9 6.35 0.6 0.043
ZZ 11.112
SSR14 OPEN 22.225 47.625 9.525 10 6.35 0.6 0.071
ZZ 12.7
SSR16 OPEN 25.4 50.8 9.525 10 6.35 0.6 0.085
ZZ 12.7
SSR18 OPEN 28.575 53.975 9.525 11 6.747 0.6 0.085
ZZ 12.7
SSR20 OPEN 31.75 57.15 9.525 11 6.747 1 0.094
ZZ 12.7
SSR22 OPEN 34.925 63.5 11.112 11 7.938 1 0.105
ZZ 14.288
SSR24 OPEN 38.1 66.675 11.112 12 7.938 1 0.14
ZZ 14.288
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SS1600 Searies
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS1601 OPEN 4.7625 17.4625 6.35 6 3.969 0.3 0.0041
ZZ.2RS 7.938
SS1602 OPEN 6.35 17.4625 6.35 6 3.969 0.3 0.0064
ZZ.2RS 7.938
SS1603 OPEN 7.9375 22.225 7.142 7 3.969 0.3 0.0095
ZZ.2RS 8.731
SS1604 OPEN 9.525 22.225 7.142 7 3.969 0.38 0.0086
ZZ.2RS 8.731
SS1605 7.938 23.017 7.938 7 3.969 0.3 0.0168
SS1606 9.525 23.017 7.938 7 3.969 0.38 0.0218
SS1607 11.1125 23.017 7.938 7 3.969 0.38 0.0222
SS1614 9.525 28.575 9.525 8 4.762 0.64 0.0349
SS1615 11.1125 28.757 9.525 8 4.762 0.64 0.0322
SS1616 12.7 28.757 9.525 8 4.762 0.64 0.0299
SS1620 11.1125 34.925 11.113 10 4.762 0.3 0.0454
SS1621 12.7 34.925 11.113 10 4.762 0.3 0.0481
SS1622 14.2875 34.925 11.113 10 4.762 0.64 0.0458
SS1623 15.875 34.925 11.113 10 4.762 0.64 ,
0.0399
SS1628 15.875 41.257 12.7 9 6.35 0.64 0.0721
SS1630 19.05 41.257 12.7 9 6.35 0.64 0.0649
SS1633 15.875 44.45 12.7 9 6.35 0.64 0.0921
SS1635 19.05 44.45 12.7 9 6.35 0.64 0.0848
STAINLESS STEEL DEEP GROOVE BALL BEARINGS SSMR SS16000 Searies
Bearing NO. Overall dimension(mm) Basic rated load(N)
d D rsmin B Dynamic Cr Static Cor
Open Close
SSMR63 3 6 0.08 2 2.5 206 78
SSMR74 4 7 0.08 2 2.5 255 108
SSMR84 4 8 0.1 2 3 392 147
SSMR85 5 8 0.08 2 2.5 274 137
SSMR95 5 9 0.1 2.5 3 500 206
SSMR105 5 10 0.1 3 4 715 245
SSMR106 6 10 0.1 2.5 3 460 196
SSMR126 6 12 0.15 3 4 833 362
SSMR117 7 11 0.1 2.5 3 451 206
SSMR137 7 13 0.15 3 4 882 343
SSMR128 8 12 0.1 2.5 3.5 509 255
SSMR148 8 14 0.15 3.5 4 823 392
Bearing NO. Bore O.D Width Ball Rmin Weight(KG)
NO. Size
SS16001 12 28 7 8 4.763 0.3 0.019
SS16002 15 32 8 9 4.763 0.3 0.025
SS16003 17 35 8 10 4.763 0.3 0.032
SS16004 20 42 8 9 6.35 0.3 0.051
SS16005 25 47 8 10 6.35 0.3 0.06
SS16006 30 55 9 11 6.747 0.3 0.091
SS16007 35 62 9 11 7.938 0.3 0.11
Bearing NO. Bore Diad(mm) Dimensions(in)or(mm) Weight (kg)
D Bi Be n m G ds
SSSB201-8 12.7 M5P0.8
SSSB201 12 0.08
SSSB202-9 14.2875 1.5748 0.866 0.472 0.2362 0.63 0.1578
SSSB202-10 15.875 40 22 12 6 16 4.5 0.07
SSSB202 15
SSSB203-11 17.4625 0.065
SSSB203 17
SSSB204-12 19.05 1.8504 1.063 0.5512 0.2756 0.708 0.1772 M5P0.8 0.12
SSSB204 20 47 25 14 7 18 4.5
SSSB205-14 22.225 M6P0.75 0.16
SSSB205-15 23.8125 2.0472 1.063 0.5906 0.2953 0.7677 0.1969
SSSB205 25.4
SSSB205-16 25 52 27 15 7.5 19.5 5
SSSB206-18 28.575 2.4409 1.122 0.63 0.315 0.8661 0.1969 M6P0.75 0.25
SSSB206 31.75
SSSB206-19 30.1625 62 30 16 8 22 5.5
SSSB207-20 31.75
SSSB207-21 33.3375
SSSB207-22 34.925 2.8346 1.3386 0.6693 0.3346 0.9252 0.2362 M8P1.0 0.37
SSSB207 35
SSSB207-23 36.5125 72 32 17 8.5 23.5 6
SSSB208-24 38.1 3.1496 1.5354 0.7087 0.3543 0.9843 0.2756 M8P1.0 0.45
SSSB208-25 39.6875
SSSB208 40 80 34 18 9 25 8
SSSB209-26 41.275
SSSB209-27 42.8625 3.3465 1.622 0.748 0.4016 1.2205 0.315 M8P1.0 0.8
SSSB209-28 44.45
SSSB209 45 85 41.2 19 10.2 31 8
SSSB210-29 46.0375
SSSB210-30 47.625 3.5433 1.7126 0.7474 0.4291 1.2835 9 M8P1.0 0.87
SSSB210-31 49.2125 90 43.5 20 10.9 32.6
SSSB210-32 50.8
SSSB210 50
SSSB211-32 50.8
SSSB211-33 52.3875
SSSB211-34 53.975 3.937 1.7835 0.8268 0.4646 1.3189 10 M8P1.0 1.1
SSSB211-35 55.5625
SSSB211 55 100 45.3 21 11.8 33.5
SSSB212-36 57.15
SSSB212-37 58.7375 4.3307 2.1142 0.8661 0.5866 1.5276 10 M10P1.25 1.3
SSSB212-38 60.325 110 53.7 22 14.9 38.8
SSB212-39 61.9125
SSSB212 60
STAINLESS STEEL EXTERNAL SPHERE BALL BEARINGS WITH HOUSING SS UC200 Searies
Bearing NO. Bore Diad(mm) Dimensions(in)or(mm) Weight (kg)
D Bi Be n m G ds
SSUC201-8 12.7 0.2
SSUC201 12 0.21
SSUC202-9 14.2875 1.8504 1.2205 0.6299 0.5 0.7205 0.1969 2001/4/28
SSUC202-10 15.875 47 31 17 12.7 18.3 5 M6P0.75 0.19
SSUC202 15 0.19
SSUC203-11 17.4625
SSUC203 17 0.18
SSUC204-12 19.05 47 1.2205 0.6693 0.5 0.7205 0.1969 2001/4/28 0.16
SSUC204 20 31 17 12.7 18.3 5 M6P0.75
SSUC205-13 20.6375 0.22
SSUC205-14 22.225 2.0472 1.3425 0.6693 0.563 0.7795 0.1969 2001/4/28 0.2
SSUC205-15 23.8125 M6P0.75
SSUC205-16 25.4 52 34.1 17 14.3 19.8 5 0.19
SSUC205 25 0.19
SSUC206-17 26.9875
SSUC206-18 28.575 2.4409 1.5 0.748 0.626 0.874 0.1969 2001/4/28 0.33
SSUC206-19 30.1625 M6P0.75 0.31
SSUC206-20 31.75 62 38.1 19 15.9 22.2 5
SSUC206 30 0.31
SSUC207-20 31.75 0.53
SSUC207-21 33.3375 0.5
SSUC207-22 34.925 2.8346 1.689 0.7874 0.689 1 0.2756 5/16-24 0.47
SSUC207-23 36.5125 M8P1.0 0.44
SSUC207 35 72 42.9 20 17.5 25.4 7 0.47
SSUC208-24 38.1 3.1496 1.937 0.8661 0.748 1.189 0.315 5/16-24 0.66
SSUC208-25 39.6875 M8P1.0 0.63
SSUC208 40 80 49.2 22 19 30.2 8 0.61
SSUC209-26 41.275 0.78
SSUC209-27 42.8625 3.3465 1.937 0.8661 0.748 1.189 0.315 5/16-24 0.74
SSUC209-28 44.45 M8P1.0 0.7
SSUC209 45 85 49.2 22 19 30.2 8 0.68
SSUC210-29 46.0375 0.83
SSUC210-30 47.625 3.5433 2.0315 0.9449 0.748 1.2835 0.3937 2003/8/24 0.78
SSUC210-31 49.2125 M10P1.25 0.77
SSUC210-32 50.8 90 51.6 24 19 32.6 10
SSUC210 50
SSUC211-32 50.8 1.35
SSUC211-33 52.3875 1.24
SSUC211-34 53.975 3.937 2.19 0.9843 0.874 1.315 0.3937 2003/8/24 1.17
SSUC211-35 55.5625 100 55.6 25 22.2 33.4 10 M10P1.25 1.19
SSUC211 55
SSUC212-36 57.15 1.65
SSUC212-37 58.7375 4.3307 2.563 1.063 1 1.563 0.3937 2003/8/24
SSUC212-38 60.325 110 65.1 27 25.4 39.7 10 M10P1.25 1.5
SSUC212-39 61.9125 1.43
SSUC212 60 1.52
<, td>0.177
Bearing No. Overall dimension(mm) Basic rated load(KN) Weight (kg)
d D B rsmin Dynamic(Cr) Static(Cor)
SS62000 Size
SS62200 10 30 14 1 5.11 2.39 0.044
SS62201 12 32 14 1 6.82 3.06 0.053
SS62202 15 35 14 1 7.64 3.72 0.065
SS62203 17 40 16 1 9.57 4.79 0.096
SS62204 20 47 18 1.5 12.84 6.65 0.145
SS62205 25 52 18 1.5 14.02 7.88 0.172
SS62206 30 62 20 1.5 19.46 11.31 0.275
SS62207 35 72 23 2 25.67 15.3 0.41
SS62208 40 80 23 2 29.52 18.14 0.616
SS62209 45 85 23 2 31.67 20.68 0.625
SS62210 50 90 23 2 35.07 23.18 0.726
SS63000 Size
SS63000 10 26 12 1 3.52 1.95
SS63001 12 28 12 1.1 3.93 2.23
SS63002 15 32 13 1.1 4.3 2.51
SS63003 17 35 14 1.1 4.62 2.79
SS63004 20 42 16 1.5 7.22 4.46
SSW6200 Size
SSW6200 10 30 14.3 1 935 510 0.045
SSW6201 12 32 15.9 1 1050 595 0.055
SSW6202 15 35 15.9 1 1340 775 0.068
SSW6203 17 40 17.5 1 1660 985 0.1
SSW6204 20 47 20.6 1.5 2220 1410 0.15
SSW6205 25 52 20.6 1.5 2430 1610
SSW6206 30 62 23.8 1.5 3350 2320 0.281
SSW6207 35 72 27 2 4450 3150 0.449
SSW6208 40 80 80 2 5050 3650 0.627
SSW6209 45 85 85 2 5650 4150 0.667
SSW6210 50 90 90 2 6050 4650 0.767
SSW6300 Size
SSW6302 15 42 19 1.5 1960 1180 0.154
SSW6303 17 47 22.2 1.5 2345 1430 0.191
SSW6304 20 52 22.2 2 2750 1715 0.209
SSW6305 25 62 25.4 2 3650 2370 0.35
SSW6306 30 72 30.2 2.5 4600 3150 0.55
SSW6307 35 80 34.9 2.5 5750 4050 0.702
SSW6308 40 90 36.5 2.5 7050 5050 1.001
SSW6309 45 100 39.7 2.5 9150 6800 1.308
SSW6310 50 110 44.4 3 10700 8100 1.701
